Development

Getting Started 

If you have never done any development for Dysruption and would like a step-by-step guide on how to launch development and production builds of the game, click here.

Dependencies

Docker – used for local development and for packaging releases
Node – used for the game server, the game client, and AWS dependencies
AWS CLI – used mainly by the AWS CDK, but also for AWS authentication
AWS CDK – used to manage the AWS resources used by the system
Git – access to project source code
Angular – used by the Front End (client)
Angular CLI – used to generate new front end components and run the development Angular server
QGIS – used to modify the geospatial database features

Docker login for command line access to stored Dysruption Docker images:

docker login registry.gitlab.nps.edu/moves/dysruption:latest

Create and Publish a New Release

Edit Version Strings

From the develop branch, modify the following files with the new version string:

shared/app-version.ts
package.json
client/package.json
shared/package.json

Edit cdk/config.txt

Add a unique identifier tag in this file. To be used with the naming of all the CDK generated resources. (e.g. “DEMO”)

Install Packages

Root Folder:

npm run init

CDK Folder:

npm install

Deploy CDK

cd cdk

cdk deploy --outputs-file ../server/cdk-outputs.json ProdStack

Create Git Release

Commit and push all above version file changes (not the config.txt)
From GitLab Deployments->New Release
- Create new Tag (e.g. 0.10.0)
- Add release title (e.g. Version 0.10.0)
- Select a Milestone if applicable
- Click Create Release

Data Development

This is the list of properties that are being used either on the client or server of the game that must be in the GIS data or Flow Solver models. The actual property names used in the data can have any name and be mapped to specific accessors using the Infrastructure Configuration objects.

By Data Model

`Node` (GIS Point Feature)

id: The unique id number for this Node so connected Arcs can find it
name: String to display to user about which Node this is
gridX: The x coordinate to move this Node in schematic view
gridY: The y coordinate to move this Node in schematic view

`Arc` (GIS Line Feature)

from: The fid of the Node this Arc is coming from
to: The fid of the Node this Arc is going to
active: Whether the Arc is enabled or disabled

Properties shared by Nodes and Arcs

visible: The visibility of a feature to players, 0: nowhere, 1: all views, 2: schematic only, 3: map only
invulnerable: Property specifying a feature that may not be attacked during a game, 1: invulnerable, 0: vulnerable
render_type: The icon to display for the feature

By Use Case

Creating a `Game` model instance

Node
- id: Read by Arcs to find the Arc’s from and `to
- name: Read by Arcs to name themselves if not given a name in GIS
- gridx: Read by Arcs connected to this Node to determine their grid coordinates
- gridy: Read by Arcs connected to this Node to determine their grid coordinates
Arc
- from: Used to find the Node this Arc starts at to determine grid coordinates
- to: Used to find the Node this Arc ends at to determine grid coordinates
- active: Initial state set based on game mode - this requirement will be removed here when scenario editors can set initial property overrides for different games/modes

In order to allow customizing the infrastructures used in Dysruption scenarios without requiring a new deployment of Dysruption, configuration objects can be added to the Dysruption DynamoDB Table to define each one. A configuration object must have the following properties defined:

Configuration File

Many of the display properties for infrastructure components can be modified in the Configuration file:

dysruption/cdk/lib/configuration-construct.ts

Infrastructure Configuration

objectKey: Always set to INFRASTRUCTURE_TYPE
id: The unique identifier for which type of infrastructure this represents (e.g. fuel)
displayName: The name of the infrastructure shown to users in the Scenario Editor
mapObjectConfiguration: A Map Object Configuration (as defined below) for every single type of map object (Nodes and Arcs) with the following required accesors:
- gisId: referencing a GIS property for the GIS ID of the map object
- name: referencing a GIS property for the human readable name of the map object
- visibility: referencing a GIS property for which views this object should show up in
  - 0: This object is invisible
  - 1: This object shows in all views
  - 2: This object only shows in the Schematic View
  - 3: This object only shows in the Map View
- vulnerable: Whether this object is vulnerable to being disabled
nodeConfiguration: A Map Object Configuration for Node map objects (points) with the following required accesors:
- gridX: referencing a GIS property for what x value this node will have in the schematic view
- gridY: referencing a GIS property for what y value this node will have in the schematic view
arcConfiguration: A Map Object Configuration for Arc map objects (lines) with the following required accesors:
- from: referencing a GIS property for the Node’s GIS id of where this arc starts from
- to: referencing a GIS property for the Node’s GIS id of where this arc goes to
- isActive: referencing a GIS property for determining if this Arc is active/enabled or not
flowSolverAddress: the AWS ARN address for where the AWS state machine this infrastructure uses during a simulation step

In the Dysruption system, Nodes on the map will merge the mapObjectConfiguration and nodeConfiguration objects to define what gets displayed and what actions a user can take on Nodes. Likewise, Arcs on the map will merge the mapObjectConfiguration and arcConfiguration objects.

Map Object Configuration

This object is a map between GIS, the Dysruption system, and the flow solver this infrastructure uses. It has the following properties:

accessors: The list of Accessors (see below) that define default values and how the Dysruption system can access GIS/Flow Solver properties
actions: The list of Actions (see below) a user can perform in each game mode
- ‘0’ is Break It Bad, ‘1’ is Fix It Fast, and ‘2’ is Save Our System
tooltipDisplay: What Display Properties (see below) will be displayed as tooltips when a user mouses over a map object
mapDisplay: What Display Properties will be shown as labels on top of a map object at all times
detailDisplay: What Display Properties will be displayed in the inspector panel when a map object is selected
styleModifiers: What Style Modifiers (see below) will be applied to objects of this type

Accessors

This is a map of Properties that either have to be defined for the Dysruption system use (see above configuration objects) or to add default values for properties the flow solver uses that aren’t defined in GIS. If the accessor is one Dysruption requires, the key in the map is listed above (e.g. name for mapObjectConfiguration), otherwise the key must be unique, but has no other requirement.

Example default accessor definition for mapObjectConfiguration:

accessors: {
  gisId: { key: 'fid', customizable: false },
  name: { key: 'name', customizable: false },
  failureProbabilityOffset: { key: 'failure_probability_offset', defaultValue: 0 },
  temperature: { key: 'temperature_property', defaultValue: 72 }
}

Actions

This is the list of actions you can perform in each game mode. The actions object is a map with three keys: 0 (Break It Bad), 1 (Fix It Fast), and 2 (Save Our System). If more game modes get added, more keys will be needed in this map. Each key’s value is a list of actions for that mode.

Each action object in this list has the following properties:

type: A unique identifier for what type of action this is, must be unique within a game mode’s list of actions
displayName: The name of the action users will see in game
className: Space separate attributes to determine the icon and other styling of this action in game
- Examples include dys-icon target, dys-icon wrench, dys-icon swap
conditions: The list of Conditions (see below) that must all be true for this action to be available for the user to perform on an object (defaults to no conditions)
modifications: The list of Property (see below) changes that will be applied when this action is performed
- property: The Property whose value will be set
- value: The value the Property will be set to
cost: How much of a user’s budget will be used when this action is performed (defaults to 500)

Example default actions for arcObjectConfiguration:

actions: {
  "0": [
    { type: 'disable', displayName: 'Attack', className: 'dys-icon target',
      conditions: [
        { __type: 'not-equal-condition', property: { key: 'xhat' }, value: 1 }
      ],
      modifications: [
        { property: { key: 'xhat' }, value: 1 }
      ],
      cost: 0
    }
  ],
  "1": [
    { type: 'enable', displayName: 'Enable', className: 'dys-icon wrench',
      conditions: [
        { __type: 'not-equal-condition', property: { key: 'xhat' }, value: 0 }
      ],
      modifications: [
        { property: { key: 'xhat' }, value: 0 }
      ],
      cost: 0
    }
  ],
  "2": [
    { type: 'repair', displayName: 'Repair', className: 'dys-icon wrench',
      conditions: [
        { __type: 'not-equal-condition', property: { key: 'xhat' }, value: 0 },
        { __type: 'not-equal-condition', property: { key: 'fci' }, value: 100 }
      ],
      modifications: [
        { property: { key: 'xhat' }, value: 0 },
        { property: { key: 'fci' }, value: 97.0 },
        { property: { key: "skip_fci_turns" }, value: 1 }
      ],
      cost: 250 },
    { type: 'replace', displayName: 'Replace', className: 'dys-icon swap',
      modifications: [
        { property: { key: 'xhat' }, value: 0 },
        { property: { key: 'fci' }, value: 100 },
        { property: { key: "skip_fci_turns" }, value: 1 }
      ],
      cost: 500 },
    { type: 'maintain', displayName: "Maintain", className: 'dys-icon checklist',
      conditions: [
        { __type: 'not-equal-condition', property: { key: 'xhat' }, value: 1 },
      ],
      modifications: [
        { property: { key: "skip_fci_turns" }, value: 1 }
      ],
      cost: 50
    }
  ],
}

Display Properties

Display properties all have the following properties to fill out:

displayName: The name that will be displayed in front of the value (defaults to undefined)
conditions: The list of Conditions necessary that must all be true to show this property (defaults to no conditions)
property: The actual Property being displayed
graphable: Whether this property is graphable or not (defaults to true)

Examples:

{ displayName: 'Supply', conditions: [{ __type: 'greater-than-condition', property: { key: 'supply' }, value: 0 }], property: { key: 'supply' } },
{ displayName: 'Demand', conditions: [{ __type: 'less-than-equal-condition', property: { key: 'supply' }, value: 0 }], property: { __type: 'absolute-property', key: 'supply' } }
{ property: { key: 'name' } }

Style Modifiers

These objects allow setting various flags to modify the visuals of the map object in game. These include setting the color theme for the infrastructure, the icons to use, how animations are determined, among other things.

Style modifiers have the following properties:

className: What flag to add to the element if all conditions are true
conditions: The list of Conditions (see below) that must all be true for this flag to be set (defaults to no conditions)

Examples:

// Styles for infrastructure type
{ className: type },
// Styles for on/off
{
  className: 'on',
  conditions: [
    { __type: 'equal-condition', property: { key: 'shortfall' }, value: 0 },
  ]
},
{
  className: 'off',
  conditions: [
    { __type: 'greater-than-condition', property: { key: 'shortfall' }, value: 0 },
  ]
},
// Styles for supply/demand
{
  className: 'supply',
  conditions: [
    { __type: 'greater-than-condition', property: { key: 'supply' }, value: 0 },
  ]
},
{
  className: 'demand',
  conditions: [
    { __type: 'less-than-equal-condition', property: { key: 'supply' }, value: 0 },
  ]
}

Property

This object is a map between the Dysruption system and the GIS/Flow Solver data. Based on the type of Property, the GIS value may be modified. All Property types have the following fields:

key: The GIS/Flow Solver property we are getting a value from or setting a value to
defaultValue: The default value we want to set in case the property does not exist in GIS on an object
customizable: Whether this property can be customized in the scenario editor or not

AbsoluteProperty

When the value is read, its absolute value will be given used instead.

Add the following fields to your configuration Property object:

__type: absolute-property

DifferenceProperty

When the value is read, it shows a value that’s the difference between two GIS/Flow Solver properties.

Add the following fields to your configuration Property object:

__type: difference-property
otherKey: The key of the GIS/Flow Solver property to subtract from the key property

InvertedProperty

When the value is read, it shows the opposite value (really only useful for values of 0 or 1).

Add the following fields to your configuration Property object:

__type: inverted-property

Conditions

These classes use Properties (see above) to check if they meet certain conditions with the current value.
